型號 | 外形尺寸 (mm) | α=15° | α=25° | 重量(kg) | ||||||||
d | D | B | 額定載荷 (KN) Cr | 額定載荷 (KN) Cor | 極限轉(zhuǎn)速 (rpm) 脂潤滑 | 極限轉(zhuǎn)速 (rpm) 油潤滑 | 額定載荷 (KN) Cr | 額定載荷 (KN) Cor | 極限轉(zhuǎn)速 (rpm) 脂潤滑 | 極限轉(zhuǎn)速 (rpm) 油潤滑 | ||
?7000 DB(DF/DT) | 10 | 26 | 16 | 8.60 | 4.95 | 37000 | 50000 | 8.1 | 4.65 | 27000 | 34000 | 0.042 |
7200 DB(DF/DT) | 10 | 30 | 18 | 8.10 | 4.70 | 32000 | 43000 | 7.55 | 4.4 | 23000 | 29000 | 0.062 |
7001 DB(DF/DT) | 12 | 28 | 16 | 9.40 | 5.85 | 32000 | 43000 | 8.8 | 5.45 | 23000 | 29000 | 0.048 |
7201 DB(DF/DT) | 12 | 32 | 20 | 13.8 | 8.55 | 30000 | 40000 | 12.1 | 7.25 | 22000 | 27000 | 0.076 |
7002 DB(DF/DT) | 15 | 32 | 18 | 10.7 | 7.4 | 28000 | 37000 | 9.95 | 6.85 | 20000 | 26000 | 0.07 |
7202 DB(DF/DT) | 15 | 35 | 22 | 14.1 | 9.15 | 26000 | 35000 | 13.2 | 8.55 | 19000 | 24000 | 0.096 |
7003 DB(DF/DT) | 17 | 35 | 20 | 11.9 | 8.95 | 25000 | 33000 | 10.9 | 8.25 | 18000 | 23000 | 0.09 |
7203 DB(DF/DT) | 17 | 40 | 24 | 17.7 | 11.8 | 23000 | 30000 | 16.5 | 11 | 17000 | 21000 | 0.14 |
7004 DB(DF/DT) | 20 | 42 | 24 | 18.0 | 13.2 | 21000 | 28000 | 16.7 | 12.2 | 15000 | 19000 | 0.158 |
7204 DB(DF/DT) | 20 | 47 | 28 | 25.2 | 18.0 | 19000 | 26000 | 23.5 | 16.8 | 14000 | 17000 | 0.224 |
7204BDB(DF/DT) | 20 | 47 | 28 | 21.6 | 15.4 | 10000 | 14000 | - | - | - | - | 0.224 |
7005 DB(DF/DT) | 25 | 47 | 24 | 20.0 | 16.0 | 18000 | 24000 | 18.3 | 14.8 | 13000 | 17000 | 0.182 |
7205 DB(DF/DT) | 25 | 52 | 30 | 26.9 | 20.5 | 17000 | 23000 | 24.9 | 19 | 12000 | 15000 | 0.27 |
7205BDB(DF/DT) | 25 | 52 | 30 | 22.7 | 17.4 | 9200 | 12000 | - | - | - | - | 0.27 |
7305BDB(DF/DT) | 25 | 62 | 34 | 37.2 | 26.6 | 8300 | 11000 | - | - | - | - | 0.486 |
7006 DB(DF/DT) | 30 | 55 | 26 | 25.7 | 22.0 | 16000 | 21000 | 23.6 | 20.2 | 11000 | 14000 | 0.266 |
7206 DB(DF/DT) | 30 | 62 | 32 | 37.4 | 29.5 | 14000 | 19000 | 34.7 | 27.4 | 10000 | 13000 | 0.416 |
7206BDB(DF/DT) | 30 | 62 | 32 | 31.6 | 25.0 | 7700 | 10000 | - | - | - | - | 0.416 |
7306BDB(DF/DT) | 30 | 72 | 38 | 47.5 | 37.9 | 6900 | 9200 | - | - | - | - | 0.724 |
7007 DB(DF/DT) | 35 | 62 | 28 | 31.0 | 27.4 | 13000 | 18000 | 28.4 | 25.2 | 9800 | 12000 | 0.34 |
7207 DB(DF/DT) | 35 | 72 | 34 | 49.4 | 40.2 | 12000 | 16000 | 45.7 | 37.3 | 8800 | 11000 | 0.59 |
7207BDB(DF/DT) | 35 | 72 | 34 | 41.6 | 34.1 | 6600 | 8800 | - | - | - | - | 0.59 |
7307BDB(DF/DT) | 35 | 80 | 42 | 52.7 | 40.5 | 6200 | 8200 | - | - | - | - | 0.95 |
7008 DB(DF/DT) | 40 | 68 | 30 | 33.4 | 31.8 | 12000 | 16000 | 30.4 | 29.2 | 8900 | 11000 | 0.42 |
7208 DB(DF/DT) | 40 | 80 | 36 | 59.1 | 50.4 | 11000 | 15000 | 54.6 | 46.7 | 8000 | 10000 | 0.764 |
7208BDB(DF/DT) | 40 | 80 | 36 | 49.7 | 42.7 | 6000 | 8000 | - | - | - | - | 0.764 |
7308BDB(DF/DT) | 40 | 90 | 46 | 64.5 | 50.5 | 5500 | 7400 | - | - | - | - | 1.314 |
7009 DB(DF/DT) | 45 | 75 | 32 | 29.6 | 38.5 | 11000 | 15000 | 36.2 | 35.4 | 8000 | 10000 | 0.52 |
7209 DB(DF/DT) | 45 | 85 | 38 | 66.3 | 57.4 | 10000 | 14000 | 61.3 | 53.2 | 7500 | 9400 | 0.86 |
7209BDB(DF/DT) | 45 | 85 | 38 | 55.8 | 48.6 | 5600 | 7500 | - | - | - | - | 0.86 |
7309BDB(DF/DT) | 45 | 100 | 50 | 82.1 | 68.2 | 4900 | 6600 | - | - | - | - | 1.75 |
7010 DB(DF/DT) | 50 | 80 | 32 | 42.2 | 43.9 | 10000 | 13000 | 38.4 | 40.2 | 7300 | 9200 | 0.58 |
7210 DB(DF/DT) | 50 | 90 | 40 | 69.6 | 63.6 | 9400 | 12000 | 64 | 58.7 | 6800 | 8500 | 0.97 |
7210BDB(DF/DT) | 50 | 90 | 40 | 58.0 | 53.3 | 5100 | 6800 | - | - | - | - | 0.97 |
7310BDB(DF/DT) | 50 | 110 | 54 | 105 | 88.6 | 4400 | 5800 | - | - | - | - | 2.28 |
7011 DB(DF/DT) | 55 | 90 | 36 | 55.4 | 57.3 | 9100 | 12000 | 50.5 | 52.5 | 6600 | 8300 | 0.84 |
7211 DB(DF/DT) | 55 | 100 | 42 | 85.9 | 84.4 | 8400 | 11000 | 79.1 | 74.2 | 6100 | 7600 | 1.27 |
7211BDB(DF/DT) | 55 | 100 | 42 | 71.6 | 67.6 | 4600 | 6100 | - | - | - | - | 1.27 |
7311BDB(DF/DT) | 55 | 120 | 58 | 121 | 104 | 4000 | 5400 | - | - | - | - | 2.9 |
7012 DB(DF/DT) | 60 | 95 | 36 | 56.9 | 61.3 | 4600 | 6200 | 51.8 | 56.1 | 6200 | 7700 | 0.9 |
7212 DB(DF/DT) | 60 | 110 | 44 | 104 | 99.0 | 7500 | 10000 | 95.7 | 91.5 | 5500 | 6900 | 1.64 |
7212BDB(DF/DT) | 60 | 110 | 44 | 86.8 | 83.3 | 4100 | 5500 | - | - | - | - | 1.64 |
7312BDB(DF/DT) | 60 | 130 | 62 | 138 | 121 | 3700 | 5000 | - | - | - | - | 3.62 |
7013 DB(DF/DT) | 65 | 100 | 36 | 60.2 | 68.7 | 7900 | 11000 | 54.7 | 62.8 | 5800 | 7200 | 0.94 |
7213 DB(DF/DT) | 65 | 120 | 46 | 119 | 117 | 7100 | 9400 | 109 | 108 | 5200 | 6400 | 2.04 |
7213BDB(DF/DT) | 65 | 120 | 46 | 99.0 | 98.7 | 3900 | 5200 | - | - | - | - | 2.04 |
7313BDB(DF/DT) | 65 | 140 | 66 | 156 | 139 | 3500 | 4600 | - | - | - | - | 4.44 |
7014 DB(DF/DT) | 70 | 110 | 40 | 76.2 | 86.0 | 7300 | 9700 | 69.3 | 78.7 | 5300 | 6600 | 1.32 |
7214 DB(DF/DT) | 70 | 125 | 48 | 123 | 120 | 6700 | 8900 | 113 | 111 | 4900 | 6100 | 2.24 |
7214BDB(DF/DT) | 70 | 125 | 48 | 103 | 101 | 3700 | 4900 | - | - | - | - | 2.24 |
7314BDB(DF/DT) | 70 | 150 | 70 | 175 | 158 | 3200 | 4300 | - | - | - | - | 5.4 |
7015 DB(DF/DT) | 75 | 115 | 40 | 78.0 | 91.3 | 6900 | 9200 | 70.9 | 83.4 | 5000 | 6300 | 1.38 |
7215 DB(DF/DT) | 75 | 130 | 50 | 140 | 141 | 6400 | 8500 | 129 | 130 | 4600 | 5800 | 2.46 |
7215BDB(DF/DT) | 75 | 130 | 50 | 116 | 119 | 3500 | 4600 | - | - | - | - | 2.46 |
7315BDB(DF/DT) | 75 | 160 | 74 | 191 | 178 | 3000 | 4000 | - | - | - | - | 6.6 |
7016 DB(DF/DT) | 80 | 125 | 44 | 95.3 | 111 | 6400 | 8500 | 86.7 | 101 | 4600 | 5800 | 1.86 |
7216 DB(DF/DT) | 80 | 140 | 52 | 151 | 155 | 5900 | 7900 | 139 | 143 | 4300 | 5400 | 3 |
7216BDB(DF/DT) | 80 | 140 | 52 | 125 | 130 | 3200 | 4300 | - | - | - | - | 3 |
7017 DB(DF/DT) | 85 | 130 | 44 | 97.6 | 117 | 6000 | 8000 | 88.6 | 107 | 4400 | 5500 | 1.94 |
7217 DB(DF/DT) | 85 | 150 | 56 | 174 | 181 | 5500 | 7400 | 160 | 167 | 4000 | 5000 | 3.74 |
7018 DB(DF/DT) | 90 | 140 | 48 | 116 | 138 | 5700 | 7500 | 106 | 127 | 4100 | 5100 | 2.52 |
7218 DB(DF/DT) | 90 | 160 | 60 | 199 | 209 | 5200 | 6900 | 183 | 193 | 3800 | 4700 | 4.6 |
7019 DB(DF/DT) | 95 | 145 | 48 | 119 | 147 | 5300 | 7100 | 108 | 134 | 3900 | 4800 | 2.64 |
7219 DB(DF/DT) | 95 | 170 | 64 | 216 | 224 | 4900 | 6500 | 198 | 207 | 3500 | 4400 | 5.56 |
7020 DB(DF/DT) | 100 | 150 | 48 | 122 | 154 | 5200 | 6900 | 111 | 141 | 3800 | 4700 | 2.74 |
7220 DB(DF/DT) | 100 | 180 | 68 | 242 | 254 | 4600 | 6100 | 223 | 235 | 3300 | 4100 | 6.64 |
7021 DB(DF/DT) | 105 | 160 | 52 | 143 | 179 | 4800 | 6400 | 130 | 164 | 3500 | 4400 | 3.46 |
7221 DB(DF/DT) | 105 | 190 | 72 | 264 | 287 | 4300 | 5700 | 243 | 265 | 3100 | 3900 | 7.9 |
7022 DB(DF/DT) | 110 | 170 | 56 | 164 | 203 | 4600 | 6100 | 149 | 186 | 3300 | 4200 | 4.28 |
7222 DB(DF/DT) | 110 | 200 | 76 | 286 | 321 | 4100 | 5400 | 263 | 297 | 3000 | 3700 | 9.3 |
7024 DB(DF/DT) | 120 | 180 | 56 | 173 | 226 | 4300 | 5700 | 157 | 206 | 3100 | 3900 | 4.54 |
7224 DB(DF/DT) | 120 | 215 | 80 | 308 | 359 | 3800 | 5000 | 283 | 332 | 2700 | 3400 | 10.98 |
